Centerforce Clutch Set, Dyad Ds, 10.4 Inch Clutch Diameter, 1-1/16 Inch X 10 Spline Input Shaft, Nodular Iron Pressure Plate – 413214810
$2,178.64
Centerforce Clutch Set, Dyad Ds, 10.4 Inch Clutch Diameter – 413214810
Description
Clutch Set; DYAD DS; 10.4 Inch Clutch Diameter; 1-1/16 Inch x 10 Spline Input Shaft; Nodular Iron Pressure Plate; 1300 Foot Pound Torque Capacity; Dual Disc; Segmented Organic Friction Material; Segmented Face Design/ Sprung Hub; Billet Steel Flywheel; 14.236 Inch Ring Gear Outside Diameter; 164 Tooth Flywheel; 6 Bolt Crank; With Pilot Bushing/ Alignment Tool/ Mounting Hardware
Attributes:
- Input Shaft Size: 1-1/16 Inch X 10 Spline
- Pressure Plate Design: Diaphragm
- Disc Diameter: 10.4 Inch
- Number Of Friction Discs: 2 Disc
- Flywheel Weight: 45.95 Pound
- Flywheel Tooth Count: 164
- Disc Friction Material: Organic
- Disc Friction Face Design: Segmented Face
- Disc Hub Design: Sprung
- Torque Holding Capacity: 1300 Feet/ Pound
- Pressure Plate Material: Nodular Iron
- Flywheel Material: Billet Steel
- Includes Throwout Bearing: No
- Includes Pilot Bearing: Yes
- Includes Alignment Tool: Yes
Features & Benefits:
- Sprung Hub Disc With Organic And Carbon Composite Material
- Holds Up To 1300 Feet Per Pound Of Torque
- 10.4 Inch Patented Multi-Disc Clutch Offers Smooth Engagement And Light Pedal
- 164 Tooth Ring Gear, 6 Bolt Crank And 0 OZ Counter Balance
- Limited 1 Year Warranty
About Product:
The Centerforce® DYAD DS 10.4 inch twin disc clutch has been developed for vehicles requiring a holding capacity of 500 to 1300 feet/ Pound of torque at the crank. The pressure plate features our patented centrifugal weight system for superior clamp load over stock and our patented ball bearing actuated pressure plate providing light pedal effort. The discs are equipped with organic segmented facings providing increased holding capacity and the sprung/ dampened drive disc provides smooth drivability. DYAD DS clutches are equipped with a lightened billet steel flywheel providing low inertia resulting in quicker RPM’s. Components are designed, machined and assembled in the USA. DYAD DS clutches are match balanced and ready for installation using the included ARP fasteners.
Additional information
| Weight | 51 lbs |
|---|---|
| Dimensions | 18 × 18 × 5.5 in |
| Brand | CENTERFORCE |
| Manufacturer Part Number | 413214810 |
Vehicle Fitment
This part fits the vehicles listed below. Always confirm fitment for your exact vehicle before ordering.
This part is compatible with 31 vehicles.
| Year | Make | Model | Trim | Engine | Notes |
|---|---|---|---|---|---|
| Loading fitment... | |||||
