Name: Edelbrock Carburetor, AVS2, 4-Barrel, 650 Cubic Feet Per Minute (cfm), Square-Flange, Electric Choke, Annular Flow Primary Boosters, Gasoline - 1906
Brand: EDELBROCK
SKU: KYS-E111906
Price: 581.65 USD
Availability: InStock

Description

Carburetor; AVS2; 4-Barrel; 650 Cubic Feet Per Minute (CFM); Square-Flange; Electric Choke; Annular Flow Primary Boosters; Gasoline; Satin

Attributes:

Condition: New
Recommended Use: Automotive Street
CFM: 650
Number Of Barrels: 4
Secondary Type: Mechanical
Fuel: Gasoline
Flange Style: Square Bore
Fuel Inlet: Dual
Finish: Stain
Choke Type: Electric
Emissions: 49 State Legal
EGR: Without EGR
Includes Gaskets: Yes
Vehicle Fit List: Chevrolet Big Block 1965-1990 Gen IV 00, Big Block 1991-1995 Gen V 00, Small Block 1955-1986 00, …

Features & Benefits:

The AVS2 Features Annular Flow Primary Boosters With A New Calibration For Improved Off Idle And Cruising Performance
The Annular Flow Booster Design Delivers Improved Fuel Atomization To Eliminate Flat Spots That May Be Encountered When The Carburetor Transitions From Idle To Full Throttle
Each Annular Booster Features Eight, Equally Spaced Orifices To Improve Fuel Metering From Idle To The Main
The Improved Flow Metering Makes This Carburetor Ideal For Use With A Wide Variety Of Small-Block And Big-Block Engines With Either Dual- Or Single-Plane Intake Manifolds
Provides Excellent Signal To The Metering System For A Modern Big-Inch Engine With A Big, Long-Duration Cam Profile
Limited 1 Year Warranty

About Product:
The AVS2 Series four-barrel is Edelbrock’s latest generation of performance carburetor that was first introduced at the 2017 SEMA Show in 650 Cubic Feet Per Minute versions for small cubic-Inch and dual-quad applications.
