Fabtech Lift Kit Suspension, Dirt Logic 2.25™, 3 Inch Front Lift, 3 Inch Rear Lift – K4108DL
$2,478.23
Fabtech Lift Kit Suspension, Dirt Logic 2.25™, 3 Inch Front Lift – K4108DL
Description
Lift Kit Suspension; Dirt Logic 2.25™; 3 Inch Front Lift; 3 Inch Rear Lift; With Front And Rear Dirt Logic Remote Reservoir Shock Absorbers; Black Components; With Front And Rear Coil Springs/ Bump Stop Extensions/ Rear Track Bar Bracket/ Front And Rear Stabilizer Bar Links/ Installation Hardware
Attributes:
- Front Lift Amount (IN): 3 Inch
- Rear Lift Amount (IN): 3 Inch
- Maximum Tire Size: 34.50 x 13.00
- Front Lift Type: Coil Spring Spacer
- Rear Lift Type: Coil Spring
- Shock Type: Nitrogen Gas Charged
- Wheel Backspacing (IN): 4.50
- Minimum Wheel Diameter: 17
- Wheel Offset (MM): -13
- Shocks: With Front And Rear Dirt Logic Remote Reservoir Shock Absorbers
- Color: Black
Features & Benefits:
- Provide A Superior Ride Quality Both On And Off-Road
- Ultimate In Suspension Performance
- Made In USA
- Fast And Trouble-Free Installation
- Limited Lifetime Warranty
About Product:
The Sport system features coil springs that are a Dual Rate design allowing for long travel suspension use offroad with a smooth highway ride. The first stage of the spring provides a soft ride with the ability to extend for additional travel. The second stage is designed to handle the payload of the vehicle and address large impact absorption at higher speeds. The Dual Rate coil springs are corner specific to the JL. This keeps the vehicle level side to side while allowing for increased suspension travel. Four bump stops extensions utilize the factory bump stops for compliant cushioning at full compression. The extensions retain the stock down travel to eliminate over cycling of the suspension and driveline. The extended length front and rear sway bar links with urethane bushings re-position the bars to work within the factory operating planes. By extending the length of the links, it prevents the sway bar from going over center and creating bind at full extension travel. A heavy-duty rear track bar bracket re-centers the axle while retaining the factory roll center of the vehicle with the increased ride height.
Additional information
| Weight | 137 lbs |
|---|---|
| Dimensions | 39 × 14.06 × 13.58 in |
| Brand | FABTECH |
| Manufacturer Part Number | K4108DL |
Vehicle Fitment
This part fits the vehicles listed below. Always confirm fitment for your exact vehicle before ordering.
This part is compatible with 72 vehicles.
| Year | Make | Model | Trim | Engine | Notes |
|---|---|---|---|---|---|
| Loading fitment... | |||||
