Fabtech Lift Kit Suspension, Dirt Logic, 3 Inch Front Lift, 1-1/2 Inch Rear Lift – K1190DL
$3,455.26
Fabtech Lift Kit Suspension, Dirt Logic, 3 Inch Front Lift – K1190DL
Description
Lift Kit Suspension; Dirt Logic; 3 Inch Front Lift; 1-1/2 Inch Rear Lift; With Front Dirt Logic Remote Reservoir Coil Over Shock Absorbers and Rear Dirt Logic Shock Absorbers In Kit; Black Component; With Front Upper Control Arms/ Rear Lift Blocks And U Bolts/ Installation Hardware
Attributes:
- Front Lift Amount (IN): 3 Inch
- Rear Lift Amount (IN): 1-1/2 Inch
- Front Lift Type: Upper Control Arms
- Rear Lift Type: Blocks And U-Bolts
- Maximum Tire Size: 33 x 12.50
- Shock Type: Nitrogen Gas Charged
- Wheel Backspacing (IN): 5.00
- Minimum Wheel Diameter: 18
- Wheel Offset (MM): -6.35
- Shocks: With Shocks In Kit
- Color: Black Components/ Silver Shock Absorbers
Features & Benefits:
- Increased Ground Clearance
- Extended Range Upper Ball Joints Provide A Smooth Quiet Ride
- Increased Fender Clearance For 33 Inch Tall Tires
- Suspension Can Be Restored To Stock
- Easy To Install
- Limited Lifetime Warranty
About Product:
This quality Upper Control Arm system provides a 3 Inch increased ride height over stock without creating suspension bind at full droop. Lift is accomplished with spacers that utilizes the factory coilover shocks for a stock ride. The Fabtech Upper Control Arms address the geometry of the front suspension with the new ride height for proper align-ability. Heavy-Duty ball joints allow for extended travel to eliminate binding. This 3 Inch system features the legendary stainless steel Dirt Logic 2.5 Coilover shocks. These Coilovers are built of the highest quality materials and will surpass all shocks in corrosion resistance due to the stainless steel body and NitroSteel ® piston rod. They will provide an outstanding ride quality both on and offroad. Rear lift features 1-1/2 Inch blocks and u-bolts with Dirt Logic 2.25 shocks for a balanced ride. Dirt Logic shocks are the only stainless steel body shock on the market that provide maximum corrosion resistance in harshest conditions.
Additional information
| Weight | 108 lbs |
|---|---|
| Dimensions | 35.75 × 15.13 × 8.75 in |
| Brand | FABTECH |
| Manufacturer Part Number | K1190DL |
Vehicle Fitment
This part fits the vehicles listed below. Always confirm fitment for your exact vehicle before ordering.
This part is compatible with 48 vehicles.
| Year | Make | Model | Trim | Engine | Notes |
|---|---|---|---|---|---|
| Loading fitment... | |||||
