Fabtech Lift Kit Suspension, 4 Inch Front Lift, 4 Inch Rear Lift – K2291DL
$3,852.09
Fabtech Lift Kit Suspension, 4 Inch Front Lift, 4 Inch Rear Lift – K2291DL
Description
Lift Kit Suspension; 4 Inch Front Lift; 4 Inch Rear Lift; With Front Dirt Logic 2.25 Remote Reservoir Shocks And Rear Dirt Logic 2.25 Shock Absorbers In Kit; Black Components/ Silver Shock Absorbers; With Front Coil Springs/ Radius Arms/ Pitman Arm/ Rear Lift Blocks And U Bolts/ track Bar Bracket/ Stabilizer Bar Brackets/ Brake Line Brackets/ Installation Hardware
Attributes:
- Front Lift Amount (IN): 4 Inch
- Rear Lift Amount (IN): 4 Inch
- Maximum Tire Size: 35 x 12.50
- Front Lift Type: Coil Spring
- Rear Lift Type: Blocks And U-Bolts
- Shock Type: Hydraulic/ Nitrogen Gas Charged
- Wheel Backspacing (IN): 4.75
- Minimum Wheel Diameter: 17
- Wheel Offset (MM): -6.35
- Shocks: With Shocks In Kit
- Color: Black Components/ Silver Shock Absorbers
Features & Benefits:
- Tubular Construction With Dimple Die Side Plate For Superior Strength And Constructed Of A Stainless Steel Body With NitroSteel ® Piston Rod For Maximum Corrosion Resistance And Durability
- Coil Springs Have Been Designed For A Very Compliant Ride Quality Both On And Offroad
- 1/4 Inch Thick Steel Bracketry Repositions The Factory Track Bar To Center The Axle Under The Vehicle With The Increased Lift Height
- Forged Steel Construction With High Strength Material That Exceeds The Factory Specifications
- Heavy-Duty 1/4 Inch Thick Steel Brackets Control The Travel Eliminating Over Cycling Of The Suspension
- 1/4 Inch Thick Steel Drop Brackets Reposition The Front Sway Bar For The Increased Ride Height
- Repositions The Factory Brake Lines Down On The Frame For The New Travel Range Without Having To Open The Brake System Which Keeps Factory Fluid System Intact
- Cast Iron Rear Lift Blocks With An Integrated Bump Stop Replaces The Stock Blocks For Additional Lift Without Changing The Ride Quality Of The Factory Rear Suspension Or Load Carrying Capacity
- Provides Excellent Damping For Offroad Use
- Limited Lifetime Warranty
About Product:
Fabtech’s Radius Arm system for the Ford Super Duty is built to handle the on and offroad demands of the truck enthusiast. This system is a complete upgrade to the factory suspension and will provide additional strength for use with oversized tires. The heart of this quality system is Fabtech’s tubular Radius Arms. The design of these arms comes from Fabtech race components built with a tubular structure reinforced by a dimple die side plate and heavy gusseting for rugged offroad use. They are an outstanding upgrade to the stock stamped arms. This Radius Arm design has been proven in over 10 years of service in military applications. High quality components with properly designed suspension geometry is what sets this system apart from all other Radius Arm suspensions. Include with this system is Dirt Logic 2.25 Stainless Steel reservoir shocks in the front and non reservoir shocks in the rear. These Dirt Logic shocks have been ride tuned to the vehicle with the Fabtech Coil Springs and oversized tires for an excellent ride quality both on and offroad.
Additional information
| Weight | 258.6 lbs |
|---|---|
| Dimensions | 45.5 × 14.5 × 13 in |
| Brand | FABTECH |
| Manufacturer Part Number | K2291DL |
Vehicle Fitment
This part fits the vehicles listed below. Always confirm fitment for your exact vehicle before ordering.
This part is compatible with 150 vehicles.
| Year | Make | Model | Trim | Engine | Notes |
|---|---|---|---|---|---|
| Loading fitment... | |||||
