ICON Vehicle Dynamics Wheel, Raider, 17 Inch Diameter X 8.5 Inch Width, 6 X 135 Millimeter/ 6 X 5.31 Inch Bolt Pattern – 3417856350SB
$327.73
ICON Vehicle Dynamics Wheel, Raider – 3417856350SB
Description
Wheel; Raider; 17 Inch Diameter x 8.5 Inch Width; 6 x 135 Millimeter/ 6 x 5.31 Inch Bolt Pattern; 6 Millimeter Offset; 5.00 Inch Backspacing; 60 Degree Conical Seat Lug; 87.10 Millimeter Center Bore; 6 Spoke; 1 Piece Cast Aluminum Construction; Satin Black; 2750 Pound Load Capacity; Compatible With TPMS (Tire Pressure Monitoring System); 40 Inch Max Tire Diameter; With Icon Vehicle Dynamics Logo Center Cap; Single
Attributes:
- Bolt Pattern Inch: Not Applicable
- Bolt Pattern Millimeter: Not Applicable
- Diameter: 17
- Width: 8.5
- Offset: 6
- Backspacing: 5.00
- Material: Aluminum
- Finish: Painted Satin
- Color: Black
- Bolt Pattern Inch: 6×5.31
- Bolt Pattern Inch: Not Applicable
- Bolt Pattern Millimeter: 6×135
- Bolt Pattern Millimeter: Not Applicable
- Lug Nut Seat Type: 60 Degree Conical
- Center Cap: See Replacement Items
- Center Bore: 87.10
- Lug Nut Design: Acorn
- Compatible With TPMS (Tire Pressure Monitoring Sys: Yes
- Basic Design: 6 Spoke
- With Inserts: No
- Load Capacity: 2750
- Size: 17×8.5
- Max Tire Diameter: 40
- Center Cap Design: Icon Vehicle Dynamics Logo
- Structural Warranty: Lifetime
- Quantity: Single
- Construction: One Piece Cast
- With Hub Centric Ring: No
- Estimated Install Time (Hours): 0.5
Features & Benefits:
- Satin Black Finish
- 1 Piece Cast Aluminum Construction
- Compatible With TPMS (Tire Pressure Monitoring System)
- With Icon Vehicle Dynamics Logo Center Cap
- Limited Lifetime Warranty
About Product:
Icon Alloys is proud to introduce our latest wheel design, the ‘Raider’. Featuring a modern 6 spoke design, sharp lines, a vented rock ring and “Icon-optimized” dimensions, this new wheel is not only designed to improve the looks of your truck or SUV, but the overall function as well. The Raider has a style that is anything but ordinary. Staying true to the Icon Alloys approach, the 17 Inch Raider has been engineered to maximize caliper clearance and optimize wheel position for un-hindered suspension travel and steering function. Backspace and wheel offset dimensions have been strategically developed to reduce scrub radius, improving all-around handling and ride quality. The Icon Alloys Raider has also been strength tested to yield a 2,750 Pound load rating – making it one of the strongest wheel options on the market. With build features such as these, it’s clear that a set of Icon Alloys Raider wheels is the perfect complement to an Icon Vehicle Dynamics suspension system.
Additional information
| Weight | 30 lbs |
|---|---|
| Dimensions | 20 × 20 × 11 in |
| Brand | ICON |
| Manufacturer Part Number | 3417856350SB |
Vehicle Fitment
This part fits the vehicles listed below. Always confirm fitment for your exact vehicle before ordering.
This part is compatible with 1,487 vehicles.
| Year | Make | Model | Trim | Engine | Notes |
|---|---|---|---|---|---|
| Loading fitment... | |||||
