Name: MSD Ignition Ignition Coil, Blaster SS, Single Tower Coil, 40000 Volts - 8207
Brand: MSD CO.
SKU: KYS-M468207
Price: 110.49 USD
Availability: InStock

Description

Ignition Coil; Blaster SS; Single Tower Coil; 40000 Volts; 0.355 Ohms Primary Resistance/4.4K Secondary Resistance/70:1 Turns Ratio/6.9mH Inductance/300mA Peak Current/220uS Spark Duration; Effective Up To 12500 RPM; Red

Attributes:

Recommended Use: Street
Coil Style: 1 Tower
Internal Construction: Epoxy Filled
Maximum Voltage: 40000 Volt
Coil Wire Attachment Type: Male/ HEI
Color: Red
Primary Resistance: 0.355 Ohm
Secondary Resistance: 4.4 Kilo Ohm
Diameter (IN): Not Applicable
Height (IN): 2.65 Inch
Includes Mounting Bracket: No
Includes Coil Wire: No
Includes Ballast Resistor: No

Features & Benefits:

Improved Output Coil For Electronic Ignitions, And MSD Ignitions
Efficient Winding Design And Assembly Creates A Compact Housing
Primary And Secondary Windings Are Encased In Ciba Polyurethane For Vibration Protection
70:1 Turns Ratio And Lower Primary Resistance Produce High Voltage Output
DuPont Rynite Housing With A Tall Tower And Brass Primary Terminals
CARB EO Approved
Limited 1 Year Warranty

About Product:
Don’t let the compact size of the blaster SS Coil fool you, because it is packed with performance! The efficient E-core windings are designed to produce high amounts of current without sacrificing the voltage output. In fact, when used with an MSD 6 series ignition, the blaster SS produces 300 Milli Ampere with a maximum voltage output of 40,000 Volts! The secondary windings are wound on a segmented bobbin which reduces the chance of voltage breakdown between the primary and secondary windings. For more protection, these windings are encased in a polyurethane compound for complete protection against vibration. The blaster SS features brass terminals and a sturdy Rynite housing. It is supplied with a 90 Degree boot, terminal and vibration mounts. A great addition to CD ignitions and some stock applications.
